CNS & pituitary tumors

Gliomas, glioneuronal tumors, and neuronal tumors

Astrocytoma, IDH mutant


Editorial Board Member: Meaghan Morris, M.D., Ph.D.
Deputy Editor-in-Chief: Chunyu Cai, M.D., Ph.D.
John DeWitt, M.D., Ph.D.

Last author update: 4 August 2022
Last staff update: 4 August 2022

Copyright: 2022, PathologyOutlines.com, Inc.

PubMed Search: Adult type diffuse gliomas astrocytoma, IDH mutant

John DeWitt, M.D., Ph.D.
Page views in 2022: 16,582
Page views in 2023 to date: 4,100
Cite this page: DeWitt J. Astrocytoma, IDH mutant. PathologyOutlines.com website. https://www.pathologyoutlines.com/topic/CNStumorgliomasastrocytomasIDHmutant.html. Accessed February 3rd, 2023.
Definition / general
  • IDH1 / IDH2 mutated, diffusely infiltrating glioma, most often with concurrent TP53 or ATRX mutations and without 1p / 19q codeletion
  • Can be graded CNS WHO grade 2, 3 or 4
Essential features
  • IDH1 codon 132 or IDH2 codon 172 mutated, diffusely infiltrating glioma without 1p / 19q codeletion and usually with TP53 or ATRX mutations
  • In the absence of 1p / 19q codeletion, a component that morphologically resembles oligodendroglioma is compatible with this diagnosis
  • Can be designated CNS WHO grade 2, 3 or 4 depending on presence of mitotic activity, nuclear atypia, pleomorphism, necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion
  • Significant proliferative activity is consistent with a CNS WHO grade 3 diagnosis
  • Presence of either necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion is consistent with a CNS WHO grade 4 diagnosis
Terminology
  • Astrocytoma, IDH mutant, CNS WHO grade 2; previously designated diffuse astrocytoma, IDH mutant
  • Astrocytoma, IDH mutant, CNS WHO grade 3; previously designated anaplastic astrocytoma, IDH mutant
  • Astrocytoma, IDH mutant, CNS WHO grade 4; previously designated glioblastoma, IDH mutant
  • Astrocytoma, IDH mutant, CNS WHO grade 4; historically referred to as secondary glioblastoma
ICD coding
  • ICD-11:
Epidemiology
  • Age of diagnosis is typically younger than glioblastoma, IDH wild type, with higher grade tumors occurring more often in older patients (third or fourth decade for grade 2 or 3, versus fifth decade for grade 4) (Acta Neuropathol 2015;129:867)
  • M > F, within grade 2 and grade 3 tumors (N Engl J Med 2015;372:2481)
  • Majority of tumors are sporadic
  • A small percentage are associated with familial cancer syndromes, such as neurofibromatosis, tuberous sclerosis and Li-Fraumeni syndrome (Neuro Oncol 2014;16:896)
Sites
Pathophysiology
  • Cell of origin is unknown, although the commonality of IDH mutation across IDH mutant astrocytoma and oligodendroglioma suggests a common histogenesis in these tumors; similarly, single cell sequencing of IDH mutant gliomas suggests this as well (Acta Neuropathol 2009;118:469, Science 2017;355:eaai8478)
Etiology
Clinical features
  • Commonly, gradual onset of symptoms
  • May present incidentally in work up for headache or following trauma (Lancet Oncol 2017;18:e315)
  • Seizures are a common symptom in cerebral hemispheric lesions
  • Changes in behavior or personality, especially in frontal lobe tumors
  • Uncommonly, site dependent neurological deficits
  • Manifestations of increased intracranial pressure
  • Often present after a clinical history of a few months of neurologic symptoms
Diagnosis
  • MRI with contrast is the preferred imaging modality
  • Diagnosis is by biopsy or surgical resection
Radiology description
  • CT:
    • Expanding, intra-axial, poorly defined mass of low density
    • Variable calcification may be seen
    • Contrast enhancement and central hypodensity due to necrosis, occur with higher grades
  • MRI:
    • T1 hypodensity and T2 hyperintensity
    • T2 hyperintensity with relative FLAIR sequence hypointensity (T2 FLAIR mismatch) is a relatively suggestive indication of IDH mutant astrocytoma (Clin Cancer Res 2017;23:6078)
    • Distortion and enlargement of involved areas, including associated cortical ribbon
    • Contrast enhancement is typically present in higher grade tumors (J Neurooncol 2019;141:327)
    • Ring-like enhancement around central necrosis typical of grade 4
Radiology images

Contributed by John DeWitt, M.D., Ph.D. and Meaghan Morris, M.D., Ph.D.

MRI axial T1 FLAIR

MRI axial T1 precontrast

MRI axial T1 postcontrast

MRI axial T1 FLAIR

MRI axial T1 postcontrast


MRI coronal T1 precontrast

MRI coronal T1 postcontrast

Bright on FLAIR

Contrast enhancing

Prognostic factors
Case reports
Treatment
  • Complete resection as extensively as is safely possible (Neuro Oncol 2015;17:868)
  • Chemotherapy (temozolomide) or radiation therapy
Gross description
  • Ill defined neoplasm with blurring of gray-white junction and expansion of the infiltrated brain areas
  • Variable textures: firm, soft, gelatinous, granular, depending on CNS WHO grade (cellularity, necrosis)
  • Variable microcystic change imparting a spongy appearance
  • Variable calcification with a gritty sensation
  • Typically invades surrounding brain without overt tissue destruction
  • Expands native structures and can give a mass-like appearance on cut section
  • Areas of granularity or softening may be present
  • Soft gray-tan tissue with variable yellow-tan necrotic material
  • Often fragmented
  • Interface of tumor with brain parenchyma is indistinct
Gross images

Images hosted on other servers:

Glioma with cystic spaces in the cerebral hemisphere

Frozen section description
  • Smear done at the time of frozen section will show astrocytic appearing tumor cells with oblong irregular nuclei with varying degrees of atypia and glial processes
  • High grade nuclear features and mitotic activity may be observed on frozen section but necrosis or microvascular proliferation (features of glioblastoma) should not be present
  • Cellular morphology can be highly variable
    • Often predominantly tumor cells with oval hyperchromatic nuclei in a fibrillary background
    • Variably present, larger cells and pleomorphism
    • Variable quantity of cells with eccentric nuclei and glassy eosinophilic cytoplasm (gemistocytes)
    • Some show predominantly small cells with little pleomorphism and scant cytoplasm
  • Sections are hypercellular showing infiltrating neoplastic cells with edema
  • Variably present mitotic figures, necrosis and microvascular proliferation
  • Vascular thromboses and myxoid background may be present
  • Smear most commonly shows predominantly smaller cells with fine fibrillar processes, elongated nuclei, nuclear atypia and may show mitotic figures
Frozen section images

Contributed by John DeWitt, M.D., Ph.D. and Meaghan Morris, M.D., Ph.D.

Astrocytoma, IDH mutant, CNS WHO grade 3

Hypercellular tissue with edema

Microvascular proliferation

Smear

Microscopic (histologic) description
  • Diffusely infiltrating tumor cells with oval to elongated astrocytic nuclei and varying appearance of tumor cytoplasm and fibrillar glial processes (Acta Neuropathol 2015;129:789)
  • At the periphery, tumor cells may infiltrate in a diffuse single cell pattern, often with entrapped neurons and axons
  • Cellular morphology is variable, even within a single tumor
  • Commonly there is a mix of cells with elongated nuclei and fine fibrillar processes, cells with eccentric nuclei and glassy eosinophilic cytoplasm (gemistocytes), larger pleomorphic cells and small cells with scant cytoplasm
  • May show oligodendroglioma-like areas
  • Myxoid background and microcyst formation may be present
  • Variable mitotic activity, cellularity and nuclear atypia depending on CNS WHO grade
  • In small biopsy specimens, the presence of 1 mitosis may be sufficient for a CNS WHO grade 3 diagnosis, while the presence of a few mitotic figures in a large resection would not be sufficient for grade 3 designation (Acta Neuropathol 2020;139:603)
  • Presence of necrosis or microvascular proliferation would be consistent with a CNS WHO grade 4 designation
Microscopic (histologic) images

Contributed by Eman Abdelzaher, M.D., Ph.D., John DeWitt, M.D., Ph.D. and Meaghan Morris, M.D., Ph.D.
Diffuse astrocytoma, NOS: low power Diffuse astrocytoma, NOS: medium power

CNS WHO grade 2 astrocytoma, NOS

Subpial accumulation

Subpial accumulation

Diffuse astrocytoma, NOS: high power

CNS WHO grade 2 astrocytoma, NOS

Perineuronal satellitosis Perineuronal satellitosis

Perineuronal satellitosis


Perivascular accumulation

Perivascular accumulation

Mitotically active

Pleomorphic hypercellular astrocytic appearance

Gemistocytic histology


Variable morphology and necrosis

Microvascular proliferation

Entrapped neurons

R132H IDH1

ATRX

p53


Ki67

Olig2

IDH

ATRX

p53

Ki67

Cytology description
Cytology images
Positive stains
Negative stains
  • ATRX
    • Loss of nuclear ATRX is typical of diffuse astrocytomas, not oligodendrogliomas or reactive gliosis (Front Oncol 2017;7:236)
    • Strong nuclear expression in nonneoplastic vasculature and cells serves as an internal control
  • Keratins (although cocktails may show cross reactivity)
  • CAM5.2, CD45, CD20, MelanA
Molecular / cytogenetics description
  • IDH1 or IDH2 mutation necessary for the diagnosis, with R132H IDH1 variant seen in > 90% of cases (Acta Neuropathol 2009;118:469)
  • Tumors negative for R132H IDH1 immunohistochemistry require IDH1 / IDH2 sequencing to determine IDH status (Neuro Oncol 2017;19:1640)
  • p53 mutation and ATRX promoter mutation nearly always present (typically absent in oligodendroglioma, IDH mutant and 1p19q codeleted) (N Engl J Med 2015;372:2481)
  • Gain of chromosome 7
  • Usually lack TERT promoter mutations
  • Presence of CDKN2A / CDKN2B homozygous deletion portends a worse prognosis and is sufficient for a CNS WHO grade 4 designation regardless of histologic features present (Acta Neuropathol 2018;136:153)
Sample pathology report
  • Brain, frontal lobe, biopsy:
    • Integrated diagnosis: astrocytoma, IDH mutant, CNS WHO grade 4
    • Histological diagnosis: astrocytoma with elevated proliferative activity and necrosis
    • WHO histological grade: 4
    • Molecular information:
      • IDH1: mutant (R132H immunohistochemistry)
      • ATRX: nuclear expression lost (consistent with mutant)
      • p53: many positive cells (immunohistochemistry; consistent with mutant)
Differential diagnosis
  • Normal brain:
    • Beware of thick sections, no nuclear atypia
    • IDH1 negative, p53 negative
  • Demyelinating disease:
    • Not infiltrative, numerous macrophages (CD68 positive)
    • IDH1 negative
  • Pilocytic astrocytoma:
    • Circumscribed and contrast enhancing, histologically compact biphasic architecture (alternating piloid and spongy areas)
    • IDH1 negative
  • Reactive gliosis:
    • Evenly distributed hypertrophic astrocytes, IDH1 negative
  • Glioblastoma, IDH wild type:
    • High grade infiltrative glial neoplasm with astrocytic differentiation, nuclear atypia, pleomorphism, elevated mitotic activity and necrosis or microvascular proliferation
    • IDH mutation is not present by immunohistochemistry or sequencing
  • Oligodendroglioma, IDH mutant and 1p / 19q codeleted:
    • Infiltrating glioma composed of round cells resembling oligodendrocytes, hyperchromatic rounded nuclei, perinuclear halos, fine branching vasculature, scattered calcifications
    • Grade 3 tumors may have increased mitotic activity, variable microvascular proliferation and variable necrosis
    • IDH1 / IDH2 mutation present by immunohistochemistry or sequencing and whole arm codeletion of chromosomes 1p and 19q must be present by molecular testing
    • ATRX alterations and TP53 mutations are typically absent (Acta Neuropathol 2012;124:615, N Engl J Med 2009;360:765)
  • Lymphoma:
    • Parenchymal lymphomas in the central nervous system are typically diffuse large B cell lymphomas, which lack the fine fibrillar cell processes typical of glial cells
    • Diffuse large B cell lymphoma in the central nervous system often shows a perivascular tumor distribution
    • Positive for CD45 and CD20 but negative for GFAP and Olig2 by immunohistochemistry
  • Metastatic disease:
    • Morphology varies by the site of origin
    • However, typically they lack the fine fibrillar processes found in glial tumors
    • Generally are negative for Olig2 and GFAP by immunohistochemistry
Board review style question #1
Which of the following is true about IDH mutant astrocytoma?

  1. Codeletion of chromosomes 1p and 19q is a characteristic molecular alteration
  2. IDH mutant astrocytomas have a significantly better prognosis than IDH wild type tumors
  3. IDH protein expression is detected in astrocytic tumors only
  4. Malignant progression to higher grades does not occur
  5. Retained nuclear ATRX is typical of IDH mutant astrocytomas
Board review style answer #1
B. IDH mutant astrocytomas have a significantly better prognosis than IDH wild type tumors

Comment Here

Reference: Astrocytoma, IDH mutant
Board review style question #2

Which of the following is true about the entity in the figure above presenting in a 50 year old man?

  1. If R132H IDH1 immunohistochemistry is negative, no further testing is necessary
  2. If R132H IDH1 immunohistochemistry is positive, ATRX staining of tumor cells is expected to be lost
  3. If R132H IDH1 immunohistochemistry is positive, ATRX staining of tumor cells is expected to be retained
  4. If R132H IDH1 immunohistochemistry is positive, patient survival is similar to glioblastoma, IDH wild type
  5. If R132H IDH1 immunohistochemistry is positive, p53 staining of tumor cells is expected to be weak and scattered
Board review style answer #2
B. If R132H IDH1 immunohistochemistry is positive, ATRX staining of tumor cells is expected to be lost. The image is consistent with an infiltrating astrocytoma with significant pleomorphism and mitotic activity. If R132H IDH1 immunohistochemistry is positive, as stated in answer B, the findings are then consistent with astrocytoma, IDH mutant, CNS WHO grade 3. Astrocytoma, IDH mutant tumors often show concurrent ATRX mutation, indicated by loss of staining in tumor cells with ATRX immunohistochemistry.

Comment Here

Reference: Astrocytoma, IDH mutant
Board review style question #3
You are working up a diffusely infiltrating glial tumor and find tumor cells are positive for R132H IDH1 and have lost ATRX. What histologic or molecular features would be consistent with a diagnosis of astrocytoma, IDH mutant, CNS WHO grade 3?

  1. CDKN2A / CDKN2B homozygous deletion
  2. Microvascular proliferation
  3. Mitoses and pleomorphism in the absence of necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion
  4. Necrosis
  5. Necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion
Board review style answer #3
C. Mitoses and pleomorphism in the absence of necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion. The presence of mitoses and pleomorphism in the absence of necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion is consistent with a diagnosis of astrocytoma, IDH mutant, CNS WHO grade 3. The presence of necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion would be consistent with astrocytoma, IDH mutant, CNS WHO grade 4. An infiltrating astrocytoma with IDH mutation and no significant proliferative activity, pleomorphism, necrosis, microvascular proliferation or CDKN2A / CDKN2B homozygous deletion would be consistent with astrocytoma, IDH mutant, CNS WHO grade 2.

Comment Here

Reference: Astrocytoma, IDH mutant
